Description
- Liquid temperature: 0
40°C (32104°F) - Applications: Wastewater, Sewage
- Frequency: 60Hz
- Motor: 2P (3600rpm) / 4P (1800rpm), Dry type
- Insulation: Class F (2–5HP), Class H (7.5–15HP)
- Protection: IP68
- Protector: Auto-cut (2–10HP), MTS & MS (15HP)
- Bearing: Ball type
- Mechanical seal: Double M.seals
- Impeller type: Open
- Upper cover: FC200
- Motor frame: FC200
- Shaft: SUS403 (2P: 2–10HP, 4P: 3–5HP), SUS420J2 (2P: 15HP, 4P: 7.5–10HP)
- Seal material: CA/CE & SiC/SiC
- Casing: FC200
- Impeller material: FC200 + Tungsten
- Casing cover: FC200 + Heat (2P), FCD700 + Heat (4P)
- Footing: FCD450 (2P), None (4P)
- Cable: VCT / H07RN-F / SJOW / SOW
- Optional: Custom configurations available
- Floating switch: For 2P models (2–3HP)
